McCormick-Deering Farmall B 1940 | |
Model history | |
---|---|
Model introduced | 1940 |
Model discontinued | 1948 |
Model status | Discontinued Discontinued |
No. produced | 93,156 (includes BN) |
Preceded by | McCormick-Deering Farmall F-14 |
Superseded by | McCormick Farmall C |
Engine Specification | |
Engine make | International |
Engine model | C-113 |
Fuel type | gasoline |
Power hp | 18 belt, 16 drawbar |
Governed rpm | 1400 |
Displacement cu in /(litre) | 113 ci |
No. of Cylinders | 4 |
Bore in (mm) | 3 in |
Stroke in (mm) | 4 in |
Cooling system | water |
Naturally aspirated, Turbo or Supercharged | NA |
Transmission Details | |
Transmission type | sliding gear |
Gearbox make | International |
Forward | 4 |
Reverse | 1 |
Drive | 2-WD |
General Data | |
Linkage Category | drawbar |
Tyre Sizes (std/options) | |
Front | 6.00-12 4-ply single |
Rear | 8-24 4-ply |
Tractor Dimensions | |
Length (inches/metres) | 108 in |
Width (inches/meters) | 79 in |
Height (inches/meters) | 65 in |
Weight (nominal) lb/kg | 1870 lb |
Turning circle (nominal) inches/meters | 15 ft |
Wheelbase | 73 in |
Other info | |
Factories | Tractor Works, Chicago, Illinois, USA |
Plow rating | 1-16" |
Nebraska Tests No. | 331 |
Approximate Cost new in (year) | $605 (1940) |
The Farmall B was built by International Harvester from 1940 to 1948 in Chicago, Illinois, USA.
Model History[]
- For Company history see
- Main article: International Harvester
The new McCormick-Deering Farmall B was closely related to the Farmall A. The main differences were the B's narrow front (tricycle) design with a standard single front wheel or optional dual wheels, plus an extended left rear axle. Moving the left rear wheel outward put the engine and transmission in the center but the driver was still offset to the right for a good view of the ground and crop below the tractor. The B had the same power as the A and was also rated as a 1-plow tractor but it was designed to cultivate two rows vs. one for the A.
Tractor Comparison[]
At $535 the 18 pto hp Farmall B was the least expensive tricycle-type tractor available in 1940. The only other models under 20 hp were the Allis-Chalmers RC, Cletrac General, John Deere H and its replacement MT, and the Oliver 60. The other companies' smallest tricycle models were over 20 hp.
Make & model | Pto hp | Displace. | Speeds | Weight (lb) | Price ($) |
---|---|---|---|---|---|
Farmall B | 18 | 113 | 4 | 2014 | 535 (1940) |
Allis-Chalmers RC | 18 | 125 | 4 | 2595 | 785 (1940) |
Allis-Chalmers C | 23 | 125 | 4 | 2155 | 595 (1942) |
B.F. Avery A | 123 | 3 | 2280 | ||
Case VC | 24 | 124 | 4 | 4290 | 625 (1940) |
Case VAC | 21 | 124 | 4 | 3173 | 710 (1942) |
Cletrac General GG | 19 | 113 | 3 | 2105 | 595 (1939) 0 |
John Deere H | 15 | 100 | 3 | 3035 | 1475 (1947) |
John Deere MT | 19 | 100 | 4 | 2700 | 1200 (1952) |
Massey-Harris 81 | 22 | 123 | 4 | 2580 | 699 (1941) |
Minneapolis-Moline RT | 24 | 165 | 4 | 2720 | |
Oliver 60 | 18 | 121 | 4 | 2450 | 1585 (1948) |
Timeline[]
- 1939 - wide-front McCormick-Deering Farmall A introduced
- 1940 - narrow-front McCormick-Deering Farmall B added
- 1946 - name shortened to McCormick Farmall B
- 1948 - replaced by McCormick Farmall C
Factory locations[]
- Tractor Works, Chicago, Illinois, USA
Specification[]
See Infobox for basic details
- Standard tires
- Front: 6.00-12 4-ply single
- Rear: 8-24 4-ply
Variations and Options[]
- Electric starting
- Pneumatic "Lift-All" implement lift system
- Adjustable front axle
- Optional tires
- Front: 4.00-15 4-ply dual (1940), 7.50-10 4-ply single or 5.00-15 4-ply dual (1941), 6.00-12 6-ply (1944)
- Rear: 9-24 4-ply (1940), 10-24 or 11-24 4-ply (1941) or 4-30 or 5-30 4-ply dual (1944)
Serial Numbers Information[]
Year | Serial no. run start[1] |
Serial no. run End[1] |
Number Built[2] | Notes |
---|---|---|---|---|
1940 | FAB6744 | 41499 | 12765 | Serial range includes Farmall A-AV-B-BN and International A |
1941 | 41500 | 80738 | 16553 | Number built includes Farmall B-BN |
1942 | 80739 | 96389 | 6305 | |
1943 | 5 | |||
1944 | 96390 | 113217 | 7933 | |
1945 | 113218 | 146699 | 12951 | |
1946 | 146700 | 182693 | 14623 | |
1947 | 182964 | 198298 | 20100 | |
1947 | 200001 | 220829 | ||
1948 | 1921 | |||
Total built | 93156 |
Preservation[]
No information on any of these tractors in preservation is currently available on here.
- Do you know of any examples to list ? There is a privately owned one in Rocky Mount, VA.
Make + Model No. | Reg No. (if known) |
Serial No. | Build-Date | Engine-Type/Make | Owner (if known) |
Photo | Were seen/Featured in | Other info |
---|---|---|---|---|---|---|---|---|
|
||||||||
|
||||||||
Please add any tractor with known reg or serial no. with Photo if possible. | ||||||||
Make & model | reg no | serial no | date built | engine | owner |
|
seen at | misc info |
Create a page (link) for an individual tractor by linking the reg or serial number using reg number or serial number in the relevant column. Then once saved click the red link to start the new page and add info on that tractor. |
