McCormick-Deering WK-40
Talk0
13,487pages on
this wiki
this wiki
 McCormick-Deering WK-40 1937 | |
| Model history | |
|---|---|
| Model introduced | 1937 |
| Model discontinued | 1940 |
| Model status | Discontinued |
| No. produced | 5,440 WK-40 and WD-40 in 1937-1940 |
| Preceded by | McCormick-Deering WA-40 |
| Superseded by | McCormick-Deering W-9 |
| Engine Specification | |
| Engine make | International |
| Fuel type | distillate |
| Power hp | 50 belt, 35 drawbar |
| Governed rpm | 1750 |
| Displacement cu in /(litre) | 298 ci |
| No. of Cylinders | 6 |
| Bore in (mm) | 3.75 in |
| Stroke in (mm) | 4.5 in |
| Cooling system | Water |
| Naturally aspirated, Turbo or Supercharged | NA |
| Transmission Details | |
| Transmission type | sliding gear |
| Gearbox make | International |
| Forward | 3 |
| Reverse | 1 |
| Drive | 2-WD |
| General Data | |
| Linkage Category | Drawbar |
| Tyre Sizes (std/options) | |
| Front | steel 34"x6" |
| Rear | steel 50"x12" |
| Tractor Dimensions | |
| Length (inches/metres) | 142 in |
| Width (inches/meters) | 66 in |
| Height (inches/meters) | 67 in |
| Weight (nominal) lb/kg | 6630 lb |
| Turning circle (nominal) inches/meters | 34 ft |
| Wheelbase | 85 in |
| Other info | |
| Factories | Milwaukee Works, Milwaukee, Wisconsin |
| Plow rating | 4 |
| Nebraska Tests No. | 269 |
| Approximate Cost new in (year) | $1305 (1940) |
The McCormick-Deering WK-40 was built by International Harvester from 1937 to 1940.
Contents |
Model history
Edit
For company history see main International Harvester article.
In 1937 McCormick-Deering WK-40 was an upgrade of the McCormick-Deering WA-40, with the engine increased to 298 ci and the rpm increased from 1,600 to 1,750. The same basic tractor was also built with a diesel engine as the McCormick-Deering WD-40. Similar industrial models were the McCormick-Deering ID-40 and International IK-40 and ID-40.
Timeline Edit
Factory locations Edit
International Harvester Milwaukee Works, Milwaukee, Wisconsin
SpecificationsEdit
See infobox for basic details
Variations and Options Edit
- 4-speed transmission replaced 3-speed in 1938
- Optional rubber tires
- 1937
- front: 7.50-20
- rear: 12.75-32
- 1938
- front: 7.50-20
- rear: 12.75-32, 13.50-32
- 1937
Serial numbers and production figuresEdit
| Year | Serial run[1] | Number Built[2] | Notes (Total WK-40 and WD-40 built in 1937-1940 was 5,440). |
|---|---|---|---|
| 1937 | WKC5120-7664 | 2545 | WK-40 & WD-40 |
| 1938 | WKC7665-9755 | 2091 | WK-40 & WD-40 |
| 1939 | WKC9756-10322 | 567 | WK-40 & WD-40 |
| 1940 | WDC10323-10559 | 275 | WK-40 & WD-40 |
Preserved modelsEdit
Add known examples in preservation ro the list below.
- Bill Koski of Owosso, Michigan owns a restored WK-40.[3]
| Make + Model No. | Reg No. (if known) | Serial No. | Build-Date | Engine-Type/Make | Owner (if known) | Photo | Were seen/Featured in | Other info |
|---|---|---|---|---|---|---|---|---|
| McCormick-Deering WK40 | 76 RNM | KC2277 | 1936 | International | B.Bowles, Wrangle |
| Carrington Steam and Tractor Rally 2011 | Restored |
| ||||||||
|
| ||||||||
|
|
| Please add any tractor with known reg or serial no. with Photo if possible. | ||||||||
| Make & model | reg no | serial no | date built | engine | owner |
| seen at | misc info |
| Create a page (link) for an individual tractor by linking the reg or serial number using reg number or serial number in the relevant column. Then once saved click the red link to start the new page and add info on that tractor. | ||||||||
Gallery Edit
Add extra photos here please.
McCormick-Deering WK-40 1940 on 7.50-20 front and 12.75-32 rear rubber tires
McCormick-Deering WK-40 engine, 1940
See alsoEdit
- List of International Harvester vehicles
- International Harvester
- Case IH
- McCormick-Deering WA-40
- McCormick-Deering WD-40
ReferencesEdit
- ↑ Wendel, C. H. 1981. 150 Years of International Harvester, Crestline Publishing Co., Sarasota, Florida. (serial numbers p.412)
- ↑ Klancher, Lee 1996. International Harvester Photographic History, Motorbooks International, Osceola, Wisconsin, p.71
- ↑ Leffingwell, Randy 1999. International Harvester Tractors, MBI Publishing Co., Osceola, Wisconsin. pp.107-109,190
